禾寶機械將於2025年3月3日-8日參與2025台北國際工具機展，攤位號:D0324，歡迎蒞臨參觀！
Home Information 2025 Taipei International Machine Tool Show｜Herbao Machinery Invites You! [2025-02-25]

Links：https://youtube.com/shorts/lVrGhcAM944?feature=share

2025 Taipei International Machine Tool Show｜
Herbao Machinery Invites You!

The 2025 Taipei International Machine Tool Show (TIMTOS) will be grandly held from March 3 to March 8 at Taipei World Trade Center Hall 1 & Nangang Exhibition Center Halls 1 & 2! TIMTOS is one of the most influential machine tool exhibitions in the world, featuring over 1,000 exhibitors and more than 6,000 booths, showcasing the latest advancements in CNC machining, precision machinery, automation, and smart manufacturing.


Herbao Machinery – Your Trusted Partner in Precision Rotary Positioning

With years of expertise in 4-axis and 5-axis rotary positioning technology, Herbao Machinery is dedicated to developing high-precision, high-rigidity, and highly stable CNC rotary positioning tables. Our products are widely used in CNC machining centers, lathes, EDM, wire cutting, and semiconductor manufacturing equipment, helping customers enhance productivity and machining accuracy.
( Read more: Technical Application #4 Breakthrough in Traditional Machining: Electrical Discharge Machining (EDM) Process )


Exhibition Highlights | Next-Gen Precision Rotary Tables

At TIMTOS 2025, Herbao Machinery will showcase a full range of rotary positioning solutions, including:
✅ YH & YHC Series – 4-axis & 5-axis NC rotary tables for high-precision machining centers
✅ RHD Series – Harmonic Gear CNC Rotary Tables, offering high precision, rigidity, and inertia, ideal for lathes, grinders, optical inspection, and honing machines
✅ SHD Series – Submersible CNC Rotary Tables, with superior waterproof and dustproof performance, perfect for EDM, wire cutting, and CNC gantry machines
✅ YHD & YHR Series – High-precision 2D CNC Rotary Tables, designed for automation, 3D printing, and multi-face laser machining


Unlock the Possibilities of Precision Manufacturing with Herbao Machinery!

Visit Us at TIMTOS 2025!

Venue: Taipei World Trade Center Hall 1 & Nangang Exhibition Center Halls 1 & 2
Date: March 3 - March 8, 2025
Herbao Machinery Booth No.: TWTC Hall 1, D0324

We warmly invite industry professionals to visit our booth and explore our latest technologies and innovative solutions!
For more information, please contact us or visit our official website.

Tel: +886-37-865907
Email: hb@herbao.com.tw
Website: www.herbao.com.tw
